Testo 635-1 Thermo-Hygrometer with Air Moisture

Model: 635-1 | Order No: 0560 6351 | UPC: 4029547004322

Testo 635-1 Thermo-Hygrometer with Air Moisture-


Downloads: datasheet manual

Testo 635-1 Thermo-Hygrometer with Air Moisture

Model: 635-1 | Order No: 0560 6351

A versatile instrument for measuring air humidity, material equilibrium moisture, and pressure dewpoint in compressed air systems.

A versatile instrument for measuring air humidity, material equilibrium moisture, and pressure dewpoint in compressed air systems.

Sale Price $378.25 USD
Regular Price $445.00 USD
Availability 1 to 2 Weeks
Quantity

Add In-House Traceable Calibration to your 0560 6351

Add In-House Traceable Calibration to your 0560 6351


Testo 635-1 Offers

Probes and printer must be ordered separately.

Provides quick and easy Humidity, Equilibrium Moisture, and Pressure Dew Point measurements. Up to 3 Temperature or Humidity probes can be displayed wirelessly. Selectable user profiles, so you can allow function buttons allocated to a specified application and menu guide facilitate intuitive operation. Material moisture can be displayed directly using special probes. To analyse humidity on ceilings and walls, Testo 635 shows the dewpoint difference between ambient air and wall surface. Precision probes up to 140°F tpd are available for checking pressure dewpoint in compressed air systems.

Wireless probes offer many advantages over traditional cable or integrated probes. There is no risk of damaging or tangling wires or cables and measurements up to 65' are possible. The optional, easily installed wireless module can be retrofitted at any time. For wireless use, a wireless module, wireless handle, and wireless probe is required. These are available as accessories.

Features

  • Compatible with wireless probes
  • Cyclical printing of readings once a minute
  • Measurement of air moisture, material equilibrium moisture, pressure dew point
  • Radio probe for temperature and humidity
  • Protection against dirt and impact (IP 54)
  • Characteristic curves allows material moisture calculation
  • 5 probe inputs
  • Range and Accuracy is probe dependant
  • PC software for analysis, filing and documentation of measurement data
  • Large, backlit display
  • Compatible with optional wireless probes
  • Fast access to the most important functions via user profiles
  • Direct display of material moisture due to freely settable characteristics curves (based on equilibrium humidity)
  • Storage of single measurements or measurement series by measurement location

Testo 635-1 Specifications

Type K (NiCr-Ni)
Measuring Range -200 to 1370°C
Accuracy ±1 Digit ±0.3°C (-60 to 60°C)
±(0.2°C + 0.3% of mv) (Remaining Range)
Resolution 0.1°C
NTC (Humidity Probe)
Measuring Range -40 to 150°C
Accuracy ±1 Digit ±0.2°C (-25 to 74.9°C)
±0.4°C (-40 to -25.1°C)
±0.4°C (75 to 99.9°C)
±0.5% of mv (Remaining Range)
Resolution 0.1°C
Testo Humidity Sensor Capacity
Measuring Range 0 to 100%RH
Resolution 0.1 %RH
Absolute Pressure Probe
Measuring Range 0 to 2000 hPa
Resolution 0.1 hPa
Click here for complete specifications on the Testo 635-1

What's included with the Testo 635-1

  • Thermo-Hygrometer with Air Moisture
  • Calibration Protocol
  • Batteries

testo 635 - U value Measurement On A Wall Of Unknown Materials

Click on a category to view a selection of compatible accessories with the Testo 635-1 Thermo-Hygrometer with Air Moisture.

Testo 0636 9835 Pressure Dewpoint Probe with Fixed Cable, 300mm 0636 9835
For measurements in compressed air systems (e.g. refrigeration dryers in the range from 0 to 2°C TPD).




Testo 0636 9836 Precision Pressure Dewpoint Probe, -40°C TPD 0636 9836
The ideal probe for highly accurate measurements in the remaining humidity range (e.g. in adsorption dryers to -50°C TPD). Includes a certificate with test point.




Testo 0636 9736 Humidity Plug-in Probe Head for Wireless Handle 0636 9736
Head measures 0 to 100% RH and -4.0° to 158.0 °F (-20 to 70°C). Requires the Testo 0554 0191 Wireless Handle for use.




Testo 0636 6160 Scatter Field Probe for the Testo 635-1 and 635-2 0636 6160
For fast and non-destructive evaluation of material moisture courses in woods and building materials.




Testo 0636 2135 Humidity Probe, Ø4mm x 60mm 0636 2135
Comes with 4 attachable PTFE caps for material equilibrium moisture measurement.




Testo 0516 0035 Carrying Case for 0560 6351 and 0563 6352 0516 1035
Hard Case for basic measuring instrument and probes. Dimensions: 400 x 310 x 96mm.




Testo 0604 9794 Air/Immersion Probe,Type K TC 0604 9794
Super quick-action plug-in probe. For measurements in gases and liquids with a low-mass tip.




Testo 0603 1793 Air Probe, Type T TC 0603 1793
Includes handle and 3.9' cable. For use with type T Thermometers.




Testo 0602 1793 Air Probe, Type K TC 0602 1793
Rugged air probe with 4ft cable. Useful for HVAC/R applications.




Testo 0628 0009 Comfort Level Probe, NTC & Hot Wire 0628 0009
For measuring degree of turbulence levels. Includes telescope and stand. Fulfills DIN 1946 Part 2 or VDI 2080 requirements.




Testo 0554 0568 Thermal Printer Paper, 6 Rolls 0554 0568
For use with the 575 Printer. Measurement data documentation legible for up to 10 years. Package of 6 rolls.




Testo 0554 0549 Universal Infrared Printer 0554 0549
Includes a Wireless Infrared Interface, 1 Roll of Thermal Paper and 4xAA Batteries.




Testo 0554 0190 Wireless Module 0554 0190
Radio frequency of 915.00 MHz FSK. For use with the 435, 556, 560, 635, 735, 925, and 926 wireless instruments.




Testo 0613 1052 Frozen Food Tip, 3.5" long 0613 1052
Corkscrew tip design for easier penitration on frozen food. For use with the 105 Hand-Held T-Bar Thermometer.




Testo 0604 0194 Surface Probe, Type K TC 0604 0194
Quick-action plug-in probe.




Testo 0603 3392 Food Probe, SS, Type T TC 0603 3392
Accurate IP67 waterproof food probe. Includes a Teflon cable.




Testo 0603 3292 Frozen Food Probe w/ T-handle, Type T TC 0603 3292
Corkscrew tip design for easier penitration on frozen food.




Testo 0603 2192 Food Probe, SS, Type T TC 0603 2192
IP67 Stainless Steel probe with PUR cable. For use with Type T Thermometers.




Testo 0603 2492 Food Penetration Probe w/ T-handle, Type T TC 0603 2492
Rugged food penetration probe with easy-grip handle for desnser foodstuffs. Includes a IP65 waterproof reinforced cable (PUR) with reinforced protection from buckling.




Testo 0636 9735 Duct Humidity & Temperature Probe 0636 9735
Includes 1m cable. ±2% RH accuracy.




Testo 0628 0020 Pipe Wrap Probe w/ Velcro, 5" max. dia., Type K TC 0628 0020
Pipe probe with Velcro. For 5" pipe diameters.




Testo 0636 9741 Humidity & Temperature Probe, 1% Reference 0636 9741
Highly accurate reference humidity/temperature probe.





Testo 0636 2161 Humidity Probe, 11.81" Long 0636 2161
Robust humidity probe measures up to 257°F, short-term up to 284°F.




Testo 0628 0022 Flexible Humidity Probe 0628 0022
Flexible humidity probe does not retain shape. For measurements in inaccessible places.




Testo 0628 0021 High Temperature/Humidity Probe 0628 0021
Rugged high temperature/humidity probe.




Testo 0603 1293 Waterproof Immersion/Penetration Probe, Type T TC 0603 1293
Includes handle and 46" cable. For use with type T Thermometers.




Testo 0603 2693 Waterproof Immersion/Penetration Needle-tip Probe, Type T TC 0603 2693
Waterproof precision immersion/penetration probe without visible penetration hole. For use with Type T Thermometers.




Testo 0628 0006 Immersion/Penetration Probe, NTC w/ 5' Cable 0628 0006
Accurate IP67 immersion/penetration probe.




Testo 0604 0593 Immersion Probe for High Temperatures, 19", Type K TC 0604 0593
Super quick-action plug-in probe. For high temperatures.




Testo 0604 0493 Immersion Probe,Type K TC 0604 0493
Super quick-action plug-in probe. For measurements in liquids.




Testo 0602 0293 Air/Immersion/Penetration Probe for Wireless Handle, Type K TC 0602 0293
Probe head for air, immersion, and penetration measurements.




Testo 0628 0026 Waterproof Penetration Probe, Needle Tip, Type K TC 0628 0026
Penetration hole is not visible. Specially designed for for food, being ideal for hamburgers, steaks, pizza, eggs etc.




Testo 0613 1051 Penetration Tip, 4" long 0613 1051
Multipurpose standard designed probe tip. For use with the 105 Hand-Held T-Bar Thermometer.




Testo 0613 1053 Penetration Tip, 7.8" long 0613 1053
Long tip design for deep temperature measurements. For use with the 105 Hand-Held T-Bar Thermometer.




Testo 0602 0394 Surface Probe for Wireless Handle, Type K TC 0602 0394
T/C probe head for surface measurement (T/C Type K).




Testo 0602 0393 Surface Probe, Spring-loaded, Type K TC 0602 0393
Fast-action surface probe with spring thermocouple, for uneven surfaces. Short-term range to 932°F.




Testo 0603 1993 Waterproof Surface Probe, Flat Tip, Type T TC 0603 1993
Waterproof surface probe with widened measurement tip for flat surfaces. For use with Type T Thermometers.




Testo 0603 0646 Flexible Oven Probe, Type K TC 0603 0646
Flexible oven probe with a PTFE cable. Tmax 250°C.




Testo 0614 1635 Temperature Probe for U-Value Measurement, 3 Sensors 0614 1635
Triple sensor system for measuring wall temperature. Includes Attachment Putty.




Testo 0628 0023 Measuring Tip w/ TC Plug, Type T TC 0628 0023
Flexible incoming goods probe, ideal for quick temperature measurements on incoming goods.
