Testo 6651 Humidity Transmitter for Critical Climate Applications

Model: 6651 | Order No: 0555 6651 | UPC: 4029547015458

Testo 6651 Humidity Transmitter for Critical Climate Applications-


Downloads: datasheet manual

Testo 6651 Humidity Transmitter for Critical Climate Applications

Model: 6651 | Order No: 0555 6651

Testo 6651 humidity/temperature transmitter for critical climate, accuracy up to ±1.7 %RH (depends on the probe), 4 to 20mA(2 wire, 24VDC) no relays or ethernet, no display, no ethernet module, no relay, 2 analog outputs.

Testo 6651 humidity/temperature transmitter for critical climate, accuracy up to ±1.7 %RH (depends on the probe), 4 to 20mA(2 wire, 24VDC) no relays or ethernet, no display, no ethernet module, no relay, 2 analog outputs.

Call for Pricing
Availability 10 to 11 Weeks

Testo 6651 Offers

This humidity/temperature transmitter for critical climate, with an accuracy up to ±1.7 %RH (depends on the probe), selectable signal outputs and 2 analog outputs.

Features

  • High-precision Testo humidity sensors with long-term stability (±1.7 % RH) can be ordered for the transmitter
  • Analog outputs enable optimum integration into individual automation systems
  • High-quality digital probes (can be ordered) and an intelligent calibration concept
  • Self-monitoring and an early warning function ensure high system availability

Applications

  • Monitoring of comfortable climate conditions
  • Storing hygroscopic substances
  • Museums and archives
  • Storing electronic components
  • Drying processes/high-humidity processes
  • Food: processing cheese, ripening fruit, drying pasta, conditioning chambers for cold meats
  • Bio research
  • Mushroom cultivation

Testo 6651 Specifications

Humidity Units Relative humidity %RH , °Ctd, °Ftd, g/m³
Meas. range 0 to 100 %RH
Temperature Units Temperature in °C / °F
Meas. range Dependent on probe (testo 660x)
Material Plastic
Dimensions 122 x 162 x 77 mm (without probe)
Cable Entry Cable bushing M16 X 1.5 (Relays: M20 X 1.5)
Channel 1 % RH min-max
Channel 2 Temperature °F min-max
Display Resolution 0.1 %RH / 0.01 °C/°F / 0.1 °Ctd/°Ftd / 1 g/m3
Click here for complete specifications on the Testo 6651

What's included with the Testo 6651

  • Testo 6651 temperature/humidity transmitter with selectable signal outputs
  • Display (optional)
  • Optional Ethernet module and optional relay (depending on the configuration)

Click on a category to view a selection of compatible accessories with the Testo 6651 Humidity Transmitter for Critical Climate Applications.

Testo 0555 6601 Standard Cable Probe 0555 6601
Room climate probe wall mounting for use with 6651 humidity transmitters, -20 to +70 °C ±1.7 percent RH.




Testo 0555 6602 Duct Probe 0555 6602
Climate probe duct mounting for use with 6651 humidity transmitters, -20 to +70 °C ±1.7 percent RH.




Testo 0555 6603 Duct Probe for Higher Process Temperatures 0555 6603
Process climate probe duct mounting for higher process temperatures. For use with 6651 humidity transmitters, -30 to 120°C.




Testo 0555 6604 Standard Cable Probe, -20 to 70 degree C 0555 6604
Climate probe with cable for use with 6651 humidity transmitter. 20 to 70 degree C range ±-1 percent.




Customer Reviews for the Testo 6651

Ask a question about Testo 6651 Humidity Transmitter for Critical Climate Applications

Testo 6651 Offers

This humidity/temperature transmitter for critical climate, with an accuracy up to ±1.7 %RH (depends on the probe), selectable signal outputs and 2 analog outputs.

Features

  • High-precision Testo humidity sensors with long-term stability (±1.7 % RH) can be ordered for the transmitter
  • Analog outputs enable optimum integration into individual automation systems
  • High-quality digital probes (can be ordered) and an intelligent calibration concept
  • Self-monitoring and an early warning function ensure high system availability

Applications

  • Monitoring of comfortable climate conditions
  • Storing hygroscopic substances
  • Museums and archives
  • Storing electronic components
  • Drying processes/high-humidity processes
  • Food: processing cheese, ripening fruit, drying pasta, conditioning chambers for cold meats
  • Bio research
  • Mushroom cultivation

Testo 6651 Specifications

Humidity Units Relative humidity %RH , °Ctd, °Ftd, g/m³
Meas. range 0 to 100 %RH
Temperature Units Temperature in °C / °F
Meas. range Dependent on probe (testo 660x)
Material Plastic
Dimensions 122 x 162 x 77 mm (without probe)
Cable Entry Cable bushing M16 X 1.5 (Relays: M20 X 1.5)
Channel 1 % RH min-max
Channel 2 Temperature °F min-max
Display Resolution 0.1 %RH / 0.01 °C/°F / 0.1 °Ctd/°Ftd / 1 g/m3
Click here for complete specifications on the Testo 6651

What's included with the Testo 6651

  • Testo 6651 temperature/humidity transmitter with selectable signal outputs
  • Display (optional)
  • Optional Ethernet module and optional relay (depending on the configuration)

Click on a category to view a selection of compatible accessories with the Testo 6651 Humidity Transmitter for Critical Climate Applications.

Testo 0555 6601 Standard Cable Probe 0555 6601
Room climate probe wall mounting for use with 6651 humidity transmitters, -20 to +70 °C ±1.7 percent RH.




Testo 0555 6602 Duct Probe 0555 6602
Climate probe duct mounting for use with 6651 humidity transmitters, -20 to +70 °C ±1.7 percent RH.




Testo 0555 6603 Duct Probe for Higher Process Temperatures 0555 6603
Process climate probe duct mounting for higher process temperatures. For use with 6651 humidity transmitters, -30 to 120°C.




Testo 0555 6604 Standard Cable Probe, -20 to 70 degree C 0555 6604
Climate probe with cable for use with 6651 humidity transmitter. 20 to 70 degree C range ±-1 percent.
